Standard equipment of ILC 180

• rack for shelves
• stainless steel perforated shelf
• water pan
• key to the lock
• pressure gas hose with quick coupler socket and hose clamp for install pressure reducer
• ethernet cable
• manufacturer's test certificate at 37°C
• instruction manual (only digital version can be downloaded from the internal memory)
• LabDesk software - can be downloaded from the internal memory

TECHNICAL DATA

air convection   natural (without fan)

chamber capacity [l]      182

working capacity [l]        135 /3/

controller           microprocessor PID

display  7" full colour touch screen

TEMPERATURE

temperature range [°C]               5°C above ambient temperature … +50°C

temperature resolution every … [°C]     0,1

temperature fluctuation at 37°C [+/-°C]*            0,1

temperature variation at 37°C [+/-°C]* 0,3

Temperature recovery time after 30 seconds door opening at 37°C [min]          6

temperature protection              class 3.1 to DIN 12880

CO2

CO2 range [%]  0-20

CO2 resolution every … [%]       0,1

CO2 measurement        IR

CO2 recovery time after 30 seconds door opening at 5 Vol.-% CO2 [min]           10

relative humidity range [%]        90-95

CHAMBER

door type           double (external solid, internal glass)

interior

Smart PRO         acid-proof stainless steel to DIN 1.4301

housing

Smart PRO         powder coated sheet

overall dims [mm] /1/

width A 710

height B              920

depth C               790

internal dims [mm]

width D               560

height E              650

depth F 500

shelves (standard | max)            3 / 6

max shelf workload [kg] /2/       10

max unit workload [kg] 30

weight [kg]         96

ELECTRICAL PARAMETERS

Energy consumption at 37°C [Wh/h]     66

voltage 230V 50/60Hz

nominal power [W]        1700

Noise level [db(A)]          42

warranty             24 months

manufacturer   POL-EKO®
