Standard equipment of ST 700

• temperature range +3…+40°C (+70°C in Smart PRO)
• chamber capacity 625 liters
• working capacity 611 liters
• quality control protocol (in +37°C)
• instruction manual in English and menu in various languages
• Over temperature protection 1.0 class (according to DIN 12880) for models C (comfort), 2.0 for models P (premium) and 3.3 class in Smart PRO
• open door alarm
• LAN port and USB port
• internal LED light
• access port to enter an external sensor (Ø30 mm) on the left side of the unit
• door lock
• stainless steel wire shelves (INOX) for models C (comfort) and P (premium)
• full external doors
• assembly kit for fixing to the wall
• WiFi communication (only Smart Pro)
• LAN cable (only Smart Pro)
• LabDesk software for, inter alia, downloading data to computer (only Smart Pro, for Smart version – optional)
• available models: C (comfort), P (premium)
• available controllers: Smart lub Smart PRO
• special models:

FOT – phytoperiodic system – day and night simulation

FIT – phytotron system – day and night simulation with intensity control

Specification:

TECHNICAL DATA

air convection                         forced

chamber capacity [l]               625

working capacity [l]                611

controller                                microprocessor PID

display                                     7" full colour touch screen

TEMPERATURE

temperature range [°C]                                  +3…+70

temperature resolution every … [°C]              0,1

temperature fluctuation at 37°C [+/-°C]*       0,3

temperature variation at 37°C [+/-°C]*          1

temperature protection                                 class 3.3 to DIN 12880

CHAMBER

door type        solid / glass or double (option) /4/

interior

C Smart PRO    stainless steel to DIN 1.4016

CS Smart PRO  stainless steel to DIN 1.4016

P Smart PRO    acid-proof stainless steel to DIN 1.4301

PS Smart PRO  acid-proof stainless steel to DIN 1.4301

housing

C Smart PRO    powder coated sheet

CS Smart PRO  stainless steel polished

P Smart PRO    powder coated sheet

PS Smart PRO  stainless steel polished

overall dims [mm] /1/

width A           730

height B           1990

depth C           900

internal dims [mm]

width D           530

width D'           600

height E           1510

depth F            680

height I            1380

shelves (standard | max)                    3 | 11

max shelf workload [kg] /2/               30

- reinforced shelf (PW) [kg] /3/          100

max unit workload [kg]                       150

weight [kg]                                          145

ELECTRICAL PARAMETERS

voltage                                                 230V 50-60Hz

nominal power [W]                             650

refrigerant                                          R290 / GWP=3

warranty                                             24 months

manufacturer                                     POL-EKO®
