Standard equipment of ST 2

• temperature range +3…+40°C (+70°C in Smart PRO)

• chamber capacity 150 liters

• working capacity 122 liters

• quality control protocol (in +37°C)

• instruction manual in English and menu in various languages

• Over temperature protection 1.0 class (according to DIN 12880) for models C (comfort), 2.0 for models P (premium) and 3.3 class in Smart PRO

• open door alarm

• LAN port and USB port

• internal LED light

• access port to enter an external sensor (Ø30 mm) on the left side of the unit

• door lock

• stainless steel wire shelves (INOX) for models C (comfort) and P (premium)

• full external doors

• WiFi communication (only Smart Pro)

• LAN cable (only Smart Pro)

• LabDesk software for, inter alia, downloading data to computer (only Smart Pro, for Smart version – optional)

• available models: C (comfort), P (premium)

• available controllers: Smart lub Smart PRO

• special models:

FOT – phytoperiodic system – day and night simulation

Specification:

TECHNICAL DATA

air convection                         forced

chamber capacity [l]               150

working capacity [l]                122

controller                                 microprocessor PID

display                                      7" full colour touch screen

TEMPERATURE

temperature range [°C]                                  +3…+40/70

temperature resolution every … [°C]              0,1

temperature fluctuation at 37°C [+/-°C]*       0,3

temperature variation at 37°C [+/-°C]*          0,5

temperature protection                                   class 3.3 to DIN 12880

CHAMBER

door type        solid / glass or double (option) /4/ interior

C Smart PRO    stainless steel to DIN 1.4016

CS Smart PRO  stainless steel to DIN 1.4016

P Smart PRO    acid-proof stainless steel to DIN 1.4301

PS Smart PRO  acid-proof stainless steel to DIN 1.4301

housing

C Smart PRO    powder coated sheet

CS Smart PRO  stainless steel polished

P Smart PRO    powder coated sheet

PS Smart PRO  stainless steel polished

overall dims [mm] /1/

width A                       610

height B                       900

depth C                       650

internal dims [mm]

width D                       480

width D'                       520

height E                       660

depth F                        420

depth F'                       480

depth G                       320

height H                      440

helves (standard | max)                      3 | 4

max shelf workload [kg] /2/               10

max unit workload [kg]                       30

weight [kg]                                            63

ELECTRICAL PARAMETERS

voltage                                    230V 50-60Hz

nominal power [W]               250

refrigerant                              R1234ze / GWP=7

warranty                                 24 months

manufacturer                         POL-EKO®
